Outer & Inner Liners: Constructed from TPU via extrusion‑through‑the‑weave technology
Operating Temperature Range: -50℃ to 70℃ (-58℉ to 158℉)
Standard Supply Lengths: 100m (330ft), 200m (660ft), 300m (990ft), 400m (1320ft)
Color Choices: Black, Red, Blue; customized shades available upon request
Hose End Configurations: Plain uncoupled ends, anodized aluminum grooved couplings; alternative fittings can be tailored as required
Key Performance Advantages:
Offers long‑term, maintenance‑free operation even in extreme harsh environments
Features superior resistance to abrasion, punctures and inter‑layer separation
Built‑in embedded copper wires provide reliable anti‑static protection
|
ID |
Tolerance |
Wall Thickness |
Service Pressure |
Minimum Burst Pressure |
Weight |
Temperature |
|
|
inch |
mm |
mm |
mm |
Psi/bar |
Psi/bar |
Kg/m |
|
|
2” |
50 |
51-53 |
3.0-4.0 |
400/28 |
1200/84 |
0.64 |
-50℃ to 70℃ -58℉ to 158℉ |
|
2.5” |
65 |
64-66 |
3.0-4.0 |
400/28 |
1200/84 |
0.75 |
|
|
3” |
80 |
76-78 |
3.5-4.5 |
400/28 |
1200/84 |
1.03 |
|
|
4” |
100 |
102-105 |
3.2-4.2 |
300/21 |
900/63 |
1.5 |
|
|
4” |
100 |
102-105 |
4.5-5.5 |
400/28 |
1200/84 |
1.73 |
|
|
4” |
100 |
102-105 |
4.0-5.0 |
660/44 |
1980/132 |
1.87 |
|
|
6” |
150 |
153-156 |
5.0-6.0 |
400/28 |
1200/84 |
3.5 |
|
|
6” |
150 |
153-156 |
5.0-6.0 |
660/44 |
1980/132 |
3.4 |
|
|
8” |
200 |
204-207 |
5.5-7.0 |
400/28 |
1200/84 |
4.9 |
|
|
10 |
250 |
254-257 |
5.0-6.0 |
300/21 |
900/63 |
5.5 |
|
|
12” |
300 |
304-308 |
5.0-6.2 |
300/21 |
900/63 |
6.6 |
|
